Cylinder type

Overview of the advantages of Cylinder Type Vibration Motors:

  • Diameter Ø4mm and Ø24,4mm
  • Length between 11,8mm and 27,1mm
  • Rated Voltage 1,3V, 3V, 5V and 7,2V
  • Vibrating force in X-Y direction
  • Available with wire, connector, spring terminal or SMD
  • Manifold methods to fix the motor inside customers application
  • Other versions on request
  • Automotive solutions for haptic feedback on request

There are 4 of 4 products shown.

BL4I2J4-C100N

  • Height [mm]: 12.2 mm
  • Rated Voltage [V]: 3 V
  • Max. Rated Speed [rpm]: 14,500 rpm
  • Max. Rated Current [mA]: 85 mA
  • Manufacturer: Baolong
BL4I2J4-C100N

BL4I2J6-PF7

  • Height [mm]: 11.4 mm
  • Rated Voltage [V]: 3 V
  • Max. Rated Speed [rpm]: 14,500 rpm
  • Max. Rated Current [mA]: 80 mA
  • Manufacturer: Baolong
BL4I2J6-PF7

BL4I2T-JC25T

  • Height [mm]: 13.2 mm
  • Rated Voltage [V]: 3 V
  • Max. Rated Speed [rpm]: 11,000 rpm
  • Max. Rated Current [mA]: 95 mA
  • Manufacturer: Baolong
BL4I2T-JC25T

BL4I2V3-X9N

  • Height [mm]: 13.2 mm
  • Rated Voltage [V]: 3 V
  • Max. Rated Speed [rpm]: 14,000 rpm
  • Max. Rated Current [mA]: 85 mA
  • Manufacturer: Baolong
BL4I2V3-X9N
